ITEM NO£ºRSC-50150
Tonnage ton(T) £º50
Work travel(mm) £º150
Cylinder Effective Area(cm2)£º78.5
Oil Capacity(L) £º1.06
Collapsed Height(mm) £º263
Extended Height(mm) £º413
Outside Dia. (Ømm) £º127
Cylinder Bore Dia.(Ømm) £º 95
Plunger Dia(Ømm) £º85
Thread for input oil-port(zg)£º3/8"-19
Saddle Protrusion from Plgr.(mm) £º26
Weight(kg) £º22 |
