Crimping rang Up to 240mm²
Crimping force 60KN
Stroke 35mm
Crimp/charge 250times(Cu 150mm2)
Crimping cycle 3s-6s(depend on the size of cable)
Capacity 3.0Ah
Voltage 18V
Charging time 2hours
Package plastic box
Accessories:
Battery 2pcs
Charger 1pcs
Sealing ring of cylinder 1set
Sealing ring of safety valve 1set
Micro computer control system-automatically detect the pressure when it is crimping,with double safety protect.
Pressure released automatically Function-the tool stop forcing the
pressing and release 90£¥ pressure when the pressure reached maximum.
The tool equipped with a double piston which characterized by a fast approach towards the connecting material and transfer to high
pressure automatically by slow crimping.
The crimping head can be smoothly turned by 350°around the longitudinal axis in order to gain better access to tight corners and other difficult working areas.
If a deviation from the set operation pressure or low btter charges is identifide,an acoustic signal sounds and a red display flashes.
One key control-press the trigger to start working,half loosing the trigger means stop forcing pressure, loosing fully means piston return to the original position.
Li-ion batteries do neither have a memory effect nor self discharge.
Evev after long periods of non operation the tool is always rady to operate.In addition we see a lower power weight ratio with 50£¥ more capacity and shorter charging cycles compare to NiMH batteries.
A Temperature sensor makes the tool stop working automatically when the tempreture over 60¡æ under long time working, the fault signal sounds, it means the tool can’t continue work the tempreture reduced to the normal. |
